PT/FM
Pocket Tracker / Fusion Machine: a tracker firmware for the M-VAVE FM-1 synthesizer, in the ProTracker tradition, whose tracks play synth engines and samples side by side.
https://hitosu.github.io/ptfm/: install it, try it in the emulator, read the manual, open the editor.
Video: INTRODUCING PT/FM on YouTube.
Status: the firmware runs on the FM-1 and is being made lighter, so more voices play at once
(dist/firmware/install.html installs it and uploads the demo disk). Its MIDI CONTROLLER (SETTINGS' MIDI
page) turns the FM-1 into a USB-MIDI controller, for the virtual FM-1 or any synth or DAW
(specs/controller.md).
What is here
| Folder | What |
|---|---|
specs/ | the specifications (specs/README.md) |
playground/ | a virtual FM-1 in the browser, for trying the UI, with sound: open playground/index.html in Chrome or Edge, click to start the sound |
panel/ | the virtual FM-1 itself, shared by the playground and the emulator |
demo-disk/ | the demo disk: patches, samples and songs under free licences, to show what PT/FM does (demo-disk/README.md) |
fw/ | the firmware (fw/README.md) |
emulator/ | the firmware running in a browser: open emulator/index.html |
dist/ | the built files, a folder for each kind of build: firmware/install.html installs the firmware and uploads the demo disk; debug/install.html installs the debug build and shows its figures; emulator/ what the emulator loads, and emulator/emulator.html the emulator as one file to share; playground/playground.html the playground as one file to share |
site/ | the web site, https://hitosu.github.io/ptfm/ (specs/site.md): the landing, and assemble.sh, which puts it together with the pages above for .github/workflows/pages.yml to publish |
tools/, tests/, assets/ | build scripts, host tests, fonts |
The layout in full: specs/layout.md. What changed from version to version: CHANGELOG.md.
Licence
GPL-3.0-only (LICENSE). Copyright (C) 2026 Vasily Kazantsev.
- PT/FM builds on SLOOP / Felucca by Leo Kuroshita (@kurogedelic), Hügelton Instruments (GPL-3.0-only). Files taken from it keep their copyright lines.
- The second core's start and hold follow work by Charles Vestal, Kerem Kilic and zednaked (GPL-3.0-only); the files that follow it carry their copyright lines.
- The Terminus fonts are SIL OFL 1.1 (
assets/fonts/Terminus-LICENSE.txt). - The firmware packages carry three files of JieLi's AC79 SDK (Apache-2.0).
- The demo disk carries its own licences, all free: demo-disk/CREDITS.md.
- Each file's header names its licence.
No warranty: custom firmware is installed at your own risk. M-VAVE and FM-1 are trademarks of their owners; PT/FM is not affiliated with them.
